| Table-L | 66.92" | 1,699.8 mm |
| Table-W | 27.56" | 700.02 mm |
| Weight on Table | 4,400 lb | 1,995.8 kg |
| Spindle Nose to Table Top | 5.91 - 29.91 | 5.91 - 29.91 |
| X - Axis Travel | 60" | 1,524 mm |
| Y - Axis Travel | 27.55" | 699.77 mm |
| Z - Axis Travel | 24" | 609.6 mm |
| Rapid Traverse Rate - X | 1,574 in/min. | 40 m/min. |
| Rapid Traverse Rate - Y | 1,574 in/min. | 40 m/min. |
| Rapid Traverse Rate - Z | 1,181 in/min. | 30 m/min. |
| Cutting Feed Rate | 797 in/min. | 20.2 m/min. |
| Spindle Speed | 15,000 RPM | 15,000 RPM |
| Spindle Taper | BT 40 | BT 40 |
| Number of Gear Ranges | 2 | 2 |
| Main Motor | 40 hp | 29.8 kW |
| Automatic Tool Changer | 48 | 48 |
| Tool Diameter | 3.23, 4.92 | 3.23, 4.92 |
| Tool Length | 11.2" | 284.48 mm |
| Tool Weight | 22 lb | 10 kg |
| Machine Weight | 24,970 lb | 11,326.2 kg |
| Control | CNC (FANUC G-TECH 31I CNC CONTROL) | CNC (FANUC G-TECH 31I CNC CONTROL) |
SPINDLE CHILLER
REMOTE PULSE GENERATOR
DUAL CHIP AUGARS
MANUALS
CHIP CONVEYOR
RENISHAW TOOL PROBE
FANUC G-TECH 31I CNC CONTROL
ROSEDALE HIGH PRESSURE COOLANT THRU SPINDLE SYSTEM
MATSUURA HIGH SPEED MACHINING G 5.1
