| Table Size - L | 71" | 1,803.4 mm |
| Table Size - W | 63" | 1,600.2 mm |
| Table Capacity | 17,600 lb | 7,983.2 kg |
| Table Indexing | .001 | .001 |
| Spindle Diameter | 5.1" | 129.54 mm |
| Spindle Taper | 50 | 50 |
| Spindle Speed | 4,000 RPM | 4,000 RPM |
| Number Of Ranges | 2 | 2 |
| Main Motor | 50 hp | 37.3 kW |
| X - Axis Travel | 118" | 2,997.2 mm |
| Y - Axis Travel | 98.4" | 2,499.4 mm |
| Z - Axis Travel | 51" | 1,295.4 mm |
| W - Axis Travel | 19" | 482.6 mm |
| Automatic Tool Changer Capacity | 80 | 80 |
| Tool Diameter | 6", 12" | 6", 12" |
| Max Tool Length | 19.7" | 500.38 mm |
| Max Tool Weight | 66 lb | 29.9 kg |
| Control | CNC (FANUC 18M CNC COLOR CONTROL) | CNC (FANUC 18M CNC COLOR CONTROL) |
COOLANT THRU THE SPINDLE
MP SCALES FOR X, Y, Z AND B AXES
SPINDLE HEAD COOLING UNIT
EASY CENTERING FUNCTION
G-COMMAND MIRROR IMAGE: G50.1, G51.1
PROGRAMMABLE PARAMTER INPUT
PARAMETER CO-ORDINATE SYSTEM ROTATION: G68,G69
200 TOTAL PAIRS OF TOOL OFFSETS
48 PAIRS OF ADDITIONAL WORKPIECE CO-ORDINATE SYSTEM
SKIP FUNCTION G31
SYNCHRONOUS TAPPING
FULL WAY COVERS
CHIP CONVEYOR
FANUC 18IM CNC CONTROL
RENISHAW PROBE
This equipment is currently unavailable. Similar equipment available now is shown below.
