| Swing Over Bed | 23.6" | 599.44 mm |
| Machining Length | 21.7" | 551.18 mm |
| Distance Between Centers | 23" | 584.2 mm |
| Distance Between Spindles | 0" | 0 mm |
| Chuck Size 1 | 10" | 254 mm |
| Spindle Nose 1 | A2 - 8 | A2 - 8 |
| Spindle Bar Capacity 1 | 3.2" | 81.28 mm |
| Turning Diameter, Shaft Diameter | 15.4" | 391.16 mm |
| Spindle Speeds 1 | 3,500 RPM | 3,500 RPM |
| Spindle Horsepower 1 | 25 hp | 18.6 kW |
| Spindle Bore Diameter 1 | 3.6" | 91.44 mm |
| Rapid Traverse Rate - X1 | 945 in/min. | 400.1 mm/sec. |
| Rapid Traverse Rate - Z1 | 1,181 in/min. | 500 mm/sec. |
| Gear Ranges | 0 | 0 |
| Turret Configuration 1 | 12 | 12 |
| Tailstock Quill Diameter | 3.1" | 78.74 mm |
| Tailstock Taper | MT 4 | MT 4 |
| Tailstock Quill Travel | 3.1" | 78.74 mm |
| Programmable Tailstock | YES | YES |
| Tailstock Travel | 22.8" | 579.12 mm |
| # Axis | 2 | 2 |
| Bar Capacity | 3.2" | 81.28 mm |
| Tailstock | YES | YES |
| Live Tooling | NO | NO |
| Sub Spindle | NO | NO |
| Control | CNC (FANUC OI-TC) | CNC (FANUC OI-TC) |
| Weight | 8140.00 | 8140.00 |
TOOL PRESETTER
DOOSAN TOOL LOAD MONITORING SYSTEM
MACRO EXECUTER
PROGRAMMABLE TAILSTOCK
BAR FEED INTERFACE
HIGH PRESSURE COOLANT INTERFACE ONLY (COOLJET NOT INCLUDED)
64 PAIRS TOOL OFFSETS
ETHERNET FUNCTION
AUTO PARTS CATCHER
FANUC OI-TC CNC CONTROL 10.4 COLOR MONITOR
LIVE CENTER MT 4
CHIP CONVEYOR
BIG BORE OPTION 3.2 BAR CAPACITY
