| Swing Over Bed | 26.8" | 680.72 mm |
| Machining Length | 82" | 2,082.8 mm |
| Distance Between Centers | 83.8" | 2,128.5 mm |
| Distance Between Spindles | 0" | 0 mm |
| Chuck Size 1 | 12" | 304.8 mm |
| Spindle Nose 1 | A2 - 11 | A2 - 11 |
| Spindle Bar Capacity 1 | 4" | 101.6 mm |
| Turning Diameter, Shaft Diameter | 16.5" | 419.1 mm |
| Spindle Speeds 1 | 3,300 RPM | 3,300 RPM |
| Spindle Horsepower 1 | 40 hp | 29.8 kW |
| Spindle Bore Diameter 1 | 4.4" | 111.76 mm |
| W - Axis Travel Sub Spindle | 0 | 0 |
| Rapid Traverse Rate - X1 | 787 in/min. | 333.2 mm/sec. |
| Rapid Traverse Rate - Z1 | 984 in/min. | 416.6 mm/sec. |
| Turret Configuration 1 | 12 | 12 |
| Turret Rotary Tool Spindle Speed 1 | 0 RPM | 0 RPM |
| Turret Rotary Tool Horse Power 1 | 0 hp | |
| Tailstock Quill Diameter | 3.94" | 100.08 mm |
| Tailstock Taper | MT 5 | MT 5 |
| Tailstock Quill Travel | 0" | 0 mm |
| Programmable Tailstock | YES | YES |
| Tailstock Travel | 55.8" | 1,417.3 mm |
| # Axis | 2 | 2 |
| Bar Capacity | 4" | 101.6 mm |
| Tailstock | 'Yes' | 'Yes' |
| Live Tooling | 'No' | 'No' |
| Sub Spindle | 'No' | 'No' |
| Control | CNC (MAZATROL MATRIX CNC CONTROL) | CNC (MAZATROL MATRIX CNC CONTROL) |
| Weight | 0.00 | 0.00 |
AUTOMATIC TOOL EYE
CHIP CONVEYOR
EIA/ISO PROGRAMMING
SPIRAL
MT 5 BUILT IN LIVE CENTER
MAZATROL MATRIX CNC CONTROL
HIGH PRESSURE COOLANT
EIA 3-D COMP
ROTATION, GEOMETRIC, AND SCALING
EXT DATA I/O
THREAD
THREAD START POINT COMPENSTION
RE-THREAD
VARIABLE 600 SETS
EIA HELICAL TAP
EIA PATTERN CYCLE
TILTED WORK PLANE
INVERSE TIME
PROGRAMMABLE TAILSTOCK
