| Control | CNC (31iA) | CNC (31iA) |
| Weight | 0.00 | 0.00 |
Pallet Size: 49.4" x 49.4"
Number Of Pallets: 2
Pallet Weight Capacity: 13,320 LBS.
Pallet Surface to Spindle Center: 2" - 61"
Pallet Center To Spindle Gage Line: 11.2" ~ 70.2"
Workpiece Dimensions: 78.7" D x 67.9"
X - Axis Travel: 82.7"
Y - Axis Travel: 59.1"
Z - Axis Travel: 59.1"
B - Axis Travel: 1 DEGREE
Rapid Traverse Rates X, Y, Z: 945, 945, 945 IPM
Rapid Traverse Rate B Axis: 0
Cutting Feed Rate: 472 IPM
Spindle Speed: 6,000 RPM
Spindle Taper: 50
Number Of Ranges: 2
Main Motor: 50 HP
Automatic Tool Changer: 90 ATC
Tool Diameter: 5.1" / 11.8"
Tool Length: 25.5"
Tool Weight: 55 LBS.
Tool Change Time: 0
Machine Weight: 68343 LBS.
FANUC 31IA CNC CONTROL
CHIP CONVEYOR
RENISHAW PART PROBE
TOOL LENGTH MEASUREMENT PROBE
COOLANT THRU SPINDLE
RIGID TAPPING
This equipment is currently unavailable. Similar equipment available now is shown below.
