| Control | CNC (FANUC 31IB WITH CELOS ERGOline Touch) | CNC (FANUC 31IB WITH CELOS ERGOline Touch) |
| Weight | 0.00 | 0.00 |
Pallet Size: 15.7" x 15.7"
Number Of Pallets: 2
Pallet Weight Capacity: 880 LBS.
Pallet Surface to Spindle Center: 3.1" ~ 25.2"
Pallet Center To Spindle Gage Line: 2.8" ~ 28.7"
Workpiece Dimensions: 24.8" X 25.4"
X - Axis Travel: 22"
Y - Axis Travel: 22"
Z - Axis Travel: 26"
B - Axis Travel: .001 Degree
Rapid Traverse Rates X, Y, Z: 2362, 2362, 2362 IPM
Rapid Traverse Rate B Axis: 0
Cutting Feed Rate: 2362 IPM
Spindle Speed: 20,000 RPM
Spindle Taper: 40 CT
Number Of Ranges: 0
Main Motor: 50 HP
Automatic Tool Changer: 60 ATC
Tool Diameter: 2.7", 6.6"
Tool Length: 17.7"
Tool Weight: 17.7"
Tool Change Time: 2.8 SECOND
Machine Weight: 16,720 LBS. w/o CPP
CHIP CONVEYOR
OPTIONAL 20,000 RPM SPINDLE
IN MACHINE MEASURING SYSTEM TABLE TOUCH SENSOR MAGNESACALE TOOL SETTER FUNCTION
COOLANT THRU SPINDLE
RENISHAW PROBE
This equipment is currently unavailable. Similar equipment available now is shown below.
