Pallet Size: 2
Number Of Pallets: 39.4" x 39.4"
Pallet Weight Capacity: 6600 LBS.
Pallet Surface to Spindle Center: 3.93" - 59"
Pallet Center To Spindle Gage Line: 5.9" - 65.94"
Workpiece Dimensions: 80.7" x 62.99"
X - Axis Travel: 66.9"
Y - Axis Travel: 55.1"
Z - Axis Travel: 60"
B - Axis Travel: .001°
Rapid Traverse Rates X, Y, Z: 2047,2047,2047 IPM
Rapid Traverse Rate B Axis: 0
Cutting Feed Rate: 2047 IPM
Spindle Speed: 8000 RPM
Spindle Taper: 50 CT
Number Of Ranges: 0
Main Motor: 50 HP
Automatic Tool Changer: 120 ATC
Tool Diameter: 10.23"
Tool Length: 25.59"
Tool Weight: 66 LBS.
Tool Change Time: 5.7 SECS.
Machine Weight: 99200 LBS.
EIA/ISO PACKAGE
RENISHAW OMP60 PART PROBE
CHIP CONVEYOR
MAZAK SUPERFLOW 1000 PSI HIGH PRESSURE COOLANT THRU SPINDLE SYSTEM
WALK WAY PLATFROM INCLUDED
SPIRAL, EIA 3D COMP, ROTATION, GEOMETRIC, SCALING, EXT-DATA I/O
SHAPE, THREAD, INVERSE, AUTO ATLM, COMPARISON STOP, G54.1, SYNC TAP
INCH/METRIC, G00 SLOPE CONST., MACRO VARIABLE 600 SETS, NAVIGATION
EIA HELICAL TAP CYCLE, MAZATROL HELICAL
MAZATROL CO-OR SHIFT MAZATROL PLANET TAP
