| Pallet Size - L | 19.7" | 500.38 mm |
| Pallet Size - W | 19.7" | 500.38 mm |
| Number of Pallets | 2 | 2 |
| Pallet Weight Capacity | 1,100 lb | 499 kg |
| Pallet Surface to Spindle Center | 3.15" ~ 28.7" | 3.15" ~ 28.7" |
| Pallet Center To Spindle Gage Line | 3.9" ~ 31.8" | 3.9" ~ 31.8" |
| Workpiece Dimensions | 31.4" x 39.3" | 31.4" x 39.3" |
| X - AxisTravel | 28.7" | 728.98 mm |
| Y - Axis Travel | 25.6" | 650.24 mm |
| Z - Axis Travel | 31.5" | 800.1 mm |
| B - Axis Travel | .001 | .001 |
| Rapid Traverse Rate - X | 1,968 in/min. | 50 m/min. |
| Rapid Traverse Rate - Y | 1968 ipm | |
| Rapid Traverse Rate - Z | 1968 ipm | |
| Cutting Feed Rate | 1,968 in/sec. | 2,999.2 m/min. |
| Spindle Speed | 14,000 RPM | 14,000 RPM |
| Spindle Taper | 40 | 40 |
| Main Motor | 30 hp | 22.4 kW |
| Automatic Tool Changer | 134 | 134 |
| Tool Diameter | 3.76" / 6.7" | 3.76" / 6.7" |
| Tool Length | 20" | 508 mm |
| Tool Weight | 24 lb | 10.9 kg |
| Tool Change Time | 0.9 sec. | 0.9 sec. |
| Machine Weight | 26,400 lb | 11,974.9 kg |
| Control | CNC (PRO 5) | CNC (PRO 5) |
| Weight | 27000.00 | 27000.00 |
FANUC 31I CNC CONTROL WITH PRO 5
FULL 4TH AXIS N/C ROTARY TABLE
CHIP REMOVAL SYSTEM
PRO 5 CONTROL
BROKEN TOOL SENSOR BTS
PORTABLE HAND HELD MPG
RIGID TAPPING
GI CONTROL
AIR DRYER SYSTEM
JV 40 HIGH PRESSURE COOLANT CHIP BLASTER
MIST BUSTER
CUSTOM MACRO/COMMON VARIABLE 600
HIGH SPEED SKIP FUNCTION
134 ATC MATRIX
NC4 TOOL LENGTH LASER PROBE
16,400 FT OF MEMORY
TOOL OFFSETS 200 PAIRS
RENISHAW OMP 400 SPINDLE PROBE
This equipment is currently unavailable. Similar equipment available now is shown below.
