| Swing Over Bed | 24" | 609.6 mm |
| Distance Between Centers | 20.16" | 512.06 mm |
| Turning Diameter, Shaft Diameter | 13.5" | 342.9 mm |
| Chuck Size 1 | 8" | 203.2 mm |
| Spindle Nose 1 | A2 - 6 | A2 - 6 |
| Spindle Bar Capacity 1 | 2" | 50.8 mm |
| Spindle Speeds 1 | 5,000 RPM | 5,000 RPM |
| Spindle Horsepower 1 | 30 hp | 22.4 kW |
| Rapid Traverse Rate - X1 | 1,181 in/min. | 500 mm/sec. |
| Rapid Traverse Rate - Z1 | 1,299 in/min. | 549.9 mm/sec. |
| Turret Configuration 1 | 12 | 12 |
| Tailstock Quill Diameter | 3.7" | 93.98 mm |
| Tailstock Taper | MT 4 | MT 4 |
| Tailstock Quill Travel | 4.1" | 104.14 mm |
| Programmable Tailstock | YES | YES |
| Tailstock Travel | 15" | 381 mm |
| # Axis | 2 | 2 |
| Bar Capacity | 2" | 50.8 mm |
| Tailstock | 'Yes' | 'Yes' |
| Live Tooling | 'No' | 'No' |
| Sub Spindle | 'No' | 'No' |
| Control | CNC (MAZAK MAZATROL MATRIX CNC COLOR CONTROL) | CNC (MAZAK MAZATROL MATRIX CNC COLOR CONTROL) |
| Weight | 10,219 | 10,219 |
Swing Over Bed: 24''
Max. Cutting Dia.: 13.5''
Distance Between Centers: 20.16''
Chuck Size: 8''
Machining Spindle Horsepower: 35 HP AC
Spindle Bore Diameter: 2.4''
Bar Capacity : 2.00''
Spindle Nose : A2-6''
Spindle Speeds: 50-5000 RPM
Turret Positions / Modified VDI: BOLT ON
Turret Configuration: 12 TOOLS
Turret Index Time: 0.2/0.6 sec.
Turret Index Time: 1 position/full
X - Axis Travel: 7.5''
Z - Axis Travel: 21''
X - Axis Travel: 1181 IPM
Z - Axis Travel: 1299 IPM
Tailstock Travel: 15''
Tailstock Quill Travel: 4.1''
Tailstock Quill Diameter: 3.7''
Machine Weight: 10,219 lbs.
RAPID TRAVERSE
MAZATROL MATRIX CNC CONVERSATIONAL CONTROL
AUTOMATIC PARTS CATCHER
COLOR LCD
AUTO TOOL PRESETTER
8'' 3 JAW HYDRAULIC CHUCK
STANDARD TOOLING PACKAGE
OPERATOR DOOR INTERLOCK
CHIP CONVEYOR
ALL AVAILABLE MANUALS
BARFEED INTERFACE
