| Table Size - L | 70.87" | 1,800.1 mm |
| Table Size - W | 62.9" | 1,597.7 mm |
| Table Capacity | 26,400 lb | 11,974.9 kg |
| Table Indexing | .001 N/C ROTARY | .001 N/C ROTARY |
| Spindle Diameter | 5.13" | 130.3 mm |
| Spindle Taper | 50.0 | 50.0 |
| Spindle Speed | 6,000 RPM | 6,000 RPM |
| Main Motor | 40 hp | 29.8 kW |
| X - Axis Travel | 118" | 2,997.2 mm |
| Y - Axis Travel | 78.74" | 2,000 mm |
| Z - Axis Travel | 63" | 1,600.2 mm |
| W - Axis Travel | 27.8" | 706.12 mm |
| Automatic Tool Changer Capacity | 40 | 40 |
| Max Tool Length | 23.6" | 599.44 mm |
| Max Tool Weight | 55 lb | 24.9 kg |
| Machine Weight | 94,600 lb | 42,909.9 kg |
| Control | CNC (FANUC 31IB CNC COLOR CONTROL) | CNC (FANUC 31IB CNC COLOR CONTROL) |
ALL MANUALS
CHIP CONVEYOR
COOLANT THRU SPINDLE SYSTEM 20 BAR
RIGID TAPPING
STEEL WAY COVERS
HIGH SPEED SPINDLE
FANUC 31I-B CNC CONTROL
SPINDLE CHILLER
AIR BLAST ON SPINDLE
Y - AXIS CLAMP
W - AXIS CLAMP
PORTABLE HAND HELD MPG
SCALES X, Y, Z,
6000 RPM SPINDLE
PCMCIA CARD SLOT
CUSTOM MACRO B
TOOL LENGTH MEASUREMENT
FULL HIGH GAURDING
This equipment is currently unavailable. Similar equipment available now is shown below.
