| Number Of Tables / Pallets | 1 | 1 |
| Table Size - L | 196" | 4,978.4 mm |
| Table Size - W | 78.7" | 1,999 mm |
| Weight on Table | 55,114 lb | 24,999.3 kg |
| Distance Between Columns | 98.4" | 2,499.4 mm |
| X - Axis Travel | 206.7" | 5,250.2 mm |
| Y - Axis Travel | 118.1" | 2,999.7 mm |
| Z - Axis Travel | 31.5" | 800.1 mm |
| Rapid Traverse Rate - X | 787 in/min. | 20 m/min. |
| Rapid Traverse Rate - Y | 787 ipm | |
| Rapid Traverse Rate - Z | 590 ipm | |
| Cutting Feedrate | 393.7 in/min. | 10 m/min. |
| Spindle Speed | 6,000 RPM | 6,000 RPM |
| Spindle Taper | 50 | 50 |
| Number Of Gear Ranges | 2 | 2 |
| Main Motor | 73.8 hp | 55 kW |
| Automatic Tool Changer | 60 | 60 |
| Tool Length | 21.7" | 551.18 mm |
| Tool Weight | 66 lb | 29.9 kg |
| Machine Weight | 101,411 lb | 45,999.3 kg |
| Control | CNC (FANUC 31IB CNC COLOR CONTROL) | CNC (FANUC 31IB CNC COLOR CONTROL) |
SEMI COVER WITH REAR TOP ROOF
SCALES X, Y, Z1, Z2 AXIS
90 DEGREE ANGLE HEAD 6000 RPM
AAC SWING 2 STATION HEAD CHANGER
PART PROGRAM STORAGE 8MB
20 BAR THROUGH SPINDLE COOLANT
RENISHAW TOOL LENGTH MEASUREMENT
DSQ 2 HIGH RAPID TRAVERSE RATE AND D CUTTING FEEDRATE
CHIP CONVEYOR
RIGID TAPPING
HAND HELD REMOTE MPG
This equipment is currently unavailable. Similar equipment available now is shown below.
