| Machining Length | 3.15" | 80.01 mm |
| Chuck Size 1 | 8" | 203.2 mm |
| Chuck Size 2 | 8" | 203.2 mm |
| Spindle Nose 1 | 5.51 | 5.51 |
| Spindle Nose 2 | 5.51 | 5.51 |
| Turning Diameter, Shaft Diameter | 5.91" | 150.11 mm |
| Spindle Speeds 1 | 4,500 RPM | 4,500 RPM |
| Spindle Speeds 2 | 4,500 RPM | 4,500 RPM |
| Spindle Horsepower 1 | 15 hp | 11.2 kW |
| Spindle Horsepower 2 | 15 hp | 11.2 kW |
| Spindle Bore Diameter 1 | 1.65" | 41.91 mm |
| Spindle Bore Diameter 2 | 1.65" | 41.91 mm |
| X1 - Axis Travel | 5.91" | 150.11 mm |
| X2 - Axis Travel | 5.91" | 150.11 mm |
| Z1 - Axis Travel | 6.1" | 154.94 mm |
| Z2 - Axis Travel | 6.1" | 154.94 mm |
| C1 - Axis Travel | 0.001 | 0.001 |
| C2 - Axis Travel | 0.001 | 0.001 |
| Rapid Traverse Rate - X1 | 945 in/min. | 400.1 mm/sec. |
| Rapid Traverse Rate- X2 | 945 in/min. | 24 m/min. |
| Rapid Traverse Rate - Z1 | 945 in/min. | 400.1 mm/sec. |
| Rapid Traverse Rate - Z2 | 945 in/min. | 24 m/min. |
| Turret Configuration 1 | 12 | 12 |
| Turret Configuration 2 | 12 station | 12 station |
| Turret Rotary Tool Spindle Speed 1 | 6,000 RPM | 6,000 RPM |
| Turret Rotary Tool Spindle Speed 2 | 6,000 RPM | 6,000 RPM |
| Turret Rotary Tool Horse Power 1 | 3.6 hp | |
| Turret Rotary Tool Horse Power 2 | 3.6 hp | 2.7 kW |
| # Axis | 3 | 3 |
| Tailstock | 'No' | 'No' |
| Live Tooling | 'Yes' | 'Yes' |
| Sub Spindle | 'No' | 'No' |
| Control | CNC (OSP P300LA CNC COLOR CONTROL) | CNC (OSP P300LA CNC COLOR CONTROL) |
| Weight | 11,100 | 11,100 |
3500 CUTTING HOURS ONLY
REAR CHIP CONVEYOR
UNIVERSAL TRANSFORMER
CHUCK OPEN CLOSE
AUTO MOON COVER OPEN CLOSE
CHUCK AIR BLOW
TOOL LIFE MANAGEMENT FUNCTION
INCH/METRIC
GANTRY LOAD OGL-3 FG E-KIT (2) TWIN 16 STATION, 5.91" DIA. X 3.15" LONG, 6.6 LBS.
CHUCK MISS DETECT AIR
COMBINATION JAWS F/LOADER
COMBINATION JAWS F/TURNOVER
TURRET AIR BLOW
(2) 8" 3 JAW HYDRAULIC CHUCK
(2) C - AXIS INDEXING .001 DEGREES
THROUGH TURRET COOLANT
OSP P300L CNC CONTROL SYSTEM
6/2018
