| Number Of Tables / Pallets | 1 | 1 |
| Table-L | 165.3" | 4,198.6 mm |
| Table-W | 80.7" | 2,049.8 mm |
| Weight on Table | 22,000 lb | 9,979 kg |
| Spindle Nose to Table Top | 5.9" ~ 37.4" | 5.9" ~ 37.4" |
| X - Axis Travel | 161.4" | 4,099.6 mm |
| Y - Axis Travel | 90.5" | 2,298.7 mm |
| Z - Axis Travel | 31.5" | 800.1 mm |
| Rapid Traverse Rate - X | 472 in/min. | 12 m/min. |
| Rapid Traverse Rate - Y | 472 in/min. | 12 m/min. |
| Rapid Traverse Rate - Z | 472 in/min. | 12 m/min. |
| Spindle Speed | 10,000 RPM | 10,000 RPM |
| Spindle Taper | 50 | 50 |
| Number of Gear Ranges | 2 | 2 |
| Main Motor | 54 hp | 40.3 kW |
| Tool Diameter | 5", 7.8" | 5", 7.8" |
| Tool Length | 15.7" | 398.78 mm |
| Tool Weight | 33 lb | 15 kg |
| Machine Weight | 90,200 lb | 40,914.1 kg |
| Automatic Tool Changer | 40 | 40 |
| Control | CNC (Fanuc 18I - MB CNC Color Control) | CNC (Fanuc 18I - MB CNC Color Control) |
| Weight | 0.00 | 0.00 |
FANUC 18IMB CNC CONTROL
SPINDLE AIR BLAST
COOLANT THRU THE SPINDLE
RIGID TAPPING
SPINDLE CHILLER
FULL ENCLOSURE
TWIN SCREW AUGERS
REMOTE PULSE GENERATOR
UPRIGHT CHIP CONVEYOR
ALL AVAILABLE MANUALS
NEW SPINDLE 4 YEARS AGO
This equipment is currently unavailable. Similar equipment available now is shown below.
