Used 2005 MAZAK HCN 6000 | Horizontal Machining Centers

Have one to sell?
(847) 669 9781
mike@usedcncllc.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
Horizontal Machining Centers
Manufacturer:
MAZAK
Model:
HCN 6000
Year:
2005
Stock #:
9953
Status:
For Sale
Pallet Size - L19.68"499.87 mm
Pallet Size - W19.68"499.87 mm
Number of Pallets22
Pallet Weight Capacity2,204 lb999.7 kg
Pallet Surface to Spindle Center5.91" - 37.4"5.91" - 37.4"
Pallet Center To Spindle Gage Line3.94" - 35.43"3.94" - 35.43"
Workpiece Dimensions35.4" x 39.37"35.4" x 39.37"
X - AxisTravel31.5"800.1 mm
Y - Axis Travel31.5"800.1 mm
Z - Axis Travel32.5"825.5 mm
B - Axis Travel1 Degree1 Degree
Rapid Traverse Rate - X2,362 in/min.60 m/min.
Rapid Traverse Rate - Y2362 ipm
Rapid Traverse Rate - Z2362 ipm
Cutting Feed Rate2,362 in/sec.3,599.7 m/min.
Spindle Speed10,000 RPM10,000 RPM
Spindle Taper#50 CT#50 CT
Main Motor50 hp37.3 kW
Automatic Tool Changer4343
Tool Diameter4.92" / 10.24"4.92" / 10.24"
Tool Length19.69"500.13 mm
Tool Weight66 lb29.9 kg
Machine Weight32,408 lb14,700 kg
ControlCNC (MAZATROL FUSION 640M)CNC (MAZATROL FUSION 640M)

MAZATROL FUSION 640M CNC CONTROL
COOLANT THRU SPINDLE
CHIP CONVEYOR
PROBE
EIA, SPIRAL, EIA 3D COMP.
ROTATION, GEOMETRIC, SCALING
EXT-DATA I/O, SHAPE COMP., THREAD
INVERSE TIME, AUTO TLM, G54.1
SYNC. TAP, INCH/MM CONVER, G00 SLOPE CONST.
VARIABLE 600 SETS, NAVIGATION, EIA HELICAL TAP
MAZATROL HELICAL, CO-OR SHIFT, PLANET TAP
