| Number Of Tables / Pallets | 1 | 1 |
| Table-L | 102.3" | 2,598.4 mm |
| Table-W | 37.4" | 949.96 mm |
| Weight on Table | 9,920 lb | 4,499.6 kg |
| Spindle Nose to Table Top | 7.9" ~ 39.4" | 7.9" ~ 39.4" |
| X - Axis Travel | 94.4" | 2,397.8 mm |
| Y - Axis Travel | 37.8" | 960.12 mm |
| Z - Axis Travel | 31.5" | 800.1 mm |
| Rapid Traverse Rate - X | 630 in/min. | 16 m/min. |
| Rapid Traverse Rate - Y | 630 in/min. | 16 m/min. |
| Rapid Traverse Rate - Z | 630 in/min. | 16 m/min. |
| Cutting Feed Rate | 0 in/min. | 0 m/min. |
| Spindle Speed | 12,000 RPM | 12,000 RPM |
| Spindle Taper | 50 BIG PLUS | 50 BIG PLUS |
| Main Motor | 40 kW | 53.6 hp |
| Automatic Tool Changer | 30 | 30 |
| Tool Diameter | 4.9", 9" | 4.9", 9" |
| Tool Length | 13.8" | 350.52 mm |
| Tool Weight | 33 lb | 15 kg |
| Machine Weight | 57,320 lb | 25,999.9 kg |
| Control | CNC (FANUC 31IB CNC COLOR CONTROL) | CNC (FANUC 31IB CNC COLOR CONTROL) |
FANUC 31IB CNC COLOR CONTROL
SMOOTH BACKLASH COMPENSATION
PART PROGRAM 640 METERS
USB MEMORY INTERFACE
AICC II 200 BLOCK
THRU SPINDLE COOLANT
RIGID TAPPING
CHIP CONVEYOR
ALL AVAILABLE MANUALS
FULL ENCLOSURE
HAND HELD REMOTE JOG HANDLE
DOOSAN TOOL LOAD MONITORING SYSTEM
TOOL LENGTH MEASUREMENT
EMBEDDED ETHERNET FUNCTION
SPINDLE CHILLER
