| Number Of Tables / Pallets | 1 | 1 |
| Table-L | 97.4" | 2,474 mm |
| Table-W | 37.4" | 949.96 mm |
| Weight on Table | 7,716 lb | 3,499.9 kg |
| Spindle Nose to Table Top | 7.9" ~ 39.4" | 7.9" ~ 39.4" |
| X - Axis Travel | 98.4" | 2,499.4 mm |
| Y - Axis Travel | 37.4" | 949.96 mm |
| Z - Axis Travel | 33.5" | 850.9 mm |
| Rapid Traverse Rate - X | 630 in/min. | 16 m/min. |
| Rapid Traverse Rate - Y | 630 in/min. | 16 m/min. |
| Rapid Traverse Rate - Z | 630 in/min. | 16 m/min. |
| Spindle Speed | 10,000 RPM | 10,000 RPM |
| Spindle Taper | 50 | 50 |
| Main Motor | 40 hp | 29.8 kW |
| Automatic Tool Changer | 30 | 30 |
| Tool Diameter | 4.9", 8.7" | 4.9", 8.7" |
| Tool Length | 13.8" | 350.52 mm |
| Tool Weight | 44 lb | 20 kg |
| Machine Weight | 50,705 lb | 22,999.4 kg |
| Control | CNC (FANUC SERIES I CNC COLOR CONTROL) | CNC (FANUC SERIES I CNC COLOR CONTROL) |
DOOSAN FANUC SERIES I CNC CONTROL
2 MB 1000 PROGRAMS 5120 METERS
EZ GUIDE CONVERSATIONAL PROGRAMMING
USB MEMORY INPUT/OUTPUT
RIGID TAPPING
THRU SPINDLE COOLANT
DOOSAN TOOL LOAD MONITORING
TOOL LENGTH MEASUREMENT
EMBEDDED ETHERNET FUNCTION
SPINDLE CHILLER
PORTABLE HAND HELD MPG
CHIP CONVEYOR
AI CONTOUR CONTROL II 200 BLOCKS
