| Swing Over Bed | 25.59" | 649.99 mm |
| Turning Diameter | 25.59" | 649.99 mm |
| Turning Length | 59.06" | 1,500.1 mm |
| Distance Between Spindles | 59.06" | 1,500.1 mm |
| Chuck Size 1 | 10" | 254 mm |
| Spindle Nose 1 | A2 - 8 | A2 - 8 |
| Spindle Bore Diameter 1 | 3.58" | 90.932 mm |
| Bar Capacity 1 | 3.15" | 80.01 mm |
| Spindle Speeds 1 | 4,200 RPM | 4,200 RPM |
| Spindle Horsepower 1 | 30 hp | 22.4 kW |
| Chuck Size 2 | 8" | 203.2 mm |
| Spindle Nose 2 | A2 - 6 | A2 - 6 |
| Spindle Bore Diameter 2 | 2.44" | 61.976 mm |
| Bar Capacity 2 | 2" | 50.8 mm |
| Spindle Speeds 2 | 5,000 RPM | 5,000 RPM |
| Spindle Horsepower 2 | 30 hp | 22.4 kW |
| B - Axis Head Indexing | 0 | 0 |
| B - Axis Milling Spindle Taper | CAPTO C 6 | CAPTO C 6 |
| B - Axis Milling Spindle Speed | 12,000 RPM | 12,000 RPM |
| B - Axis Milling Spindle Horse Power | 33 hp | 24.6 kW |
| ATC For Milling Spindle | 120 | 120 |
| Tool Length | 15.75" | 400.05 mm |
| Tool Weight | 22 lb | 10 kg |
| X1 - Axis Travel | 25.39" | 644.91 mm |
| X2 - Axis Travel | 9.25" | 234.95 mm |
| Z1 - Axis Travel | 62.99" | 1,599.9 mm |
| Z2 - Axis Travel | 57.52" | 1,461 mm |
| Y1 - Axis Travel | 9.84" | 249.94 mm |
| C - Axis Indexing 1 | 0.0001 | 0.0001 |
| C - Axis Indexing 2 | 0.0001 | 0.0001 |
| W - Axis Travel Sub Spindle | 62.36" | 1,583.9 mm |
| Rapid Traverse Rate - X1 | 1970 ipm | |
| Rapid Traverse Rate - X2 | 1970 ipm | |
| Rapid Traverse Rate - Z1 | 1970 ipm | |
| Rapid Traverse Rate - Z2 | 1970 ipm | |
| Rapid Traverse Rate - Y1 | 1576 ipm | |
| Turret Tool Positions 1 | 12 station | 12 station |
| Programmable Tailstock | 'No' | 'No' |
| Machine Weight | 38,500 lb | 17,463.3 kg |
| Control | CNC (OSP - P300H CNC COLOR CONTROL) | CNC (OSP - P300H CNC COLOR CONTROL) |
OKUMA OSP-P300 SH 1 MICRON CNC CONTROL
AOT IGF P4-ATC
OFF CENTER TURNING FUNCTION
C-AXIS SYNCHRONIZE FUNCTION
NEGATIVE TOOL RADIUS COMPENSATION
SPARE M-CODES 8 SETS
A2-8 BORE (BIG BORE OPTION)
ATC 120 CAPTO C6 AUTO TOOL CHANGE CAPACITY
TOUCHSETTER A FOR 2S
CHIP CONVEYOR HINGE/FILTER 1500BCD
LOSMA MIST COOLECT SYSTEM
PARTS CATCHER INSIDE BUCKET 220MM OUTSIDE PARTS CHUTE AND CONVEYOR
12 POSITION LOWER TURRET
DUAL TRANSFORMER 220 / 480 V
RENISHAW PART PROBE
AUTO IN PROCESS GAUGING RENISHAW RMP 60 C6 CAPTO PROBE
THRU SPINDLE COOLANT B TYPE SUB
DUAL AUTO DOOR
Y AXIS GAUGING
C- AXIS AUTO ZERO OFFSET FUNCTION
8 SPARE M CODES
5 AXIS MACHINING KIT
C AXIS SYNCHRONIZED FUNCTION
TURRET AIR BLOW
TMAC 8 ADAPTIVE CONTINUOUS MONITOR UNCTION
SUB SPINDLE TAILSTOCK FUNCTION
HI / LOW CLAMPING PRESSURE MAIN / SUB
WISKER TOOL BREAKAGE DETECTION
GOSIINGER LASER PROXI SWITCH SYSTEM FOR MANUAL CLAMPING ON MAIN & SUB
COOLANT TEMPERATURE REGULATOR
MP 1000 PSI HIGH PRESSURE COOLANT SYSTEM
SPINDLE CHILLER
NC B AXIS CONTOURING
ROBOT INTERFACE
