| Number Of Tables / Pallets | 1 | 1 |
| Table-L | 102.3" | 2,598.4 mm |
| Table-W | 37.4" | 949.96 mm |
| Weight on Table | 9,920 lb | 4,499.6 kg |
| Spindle Nose to Table Top | 7.9" - 39.4" | 7.9" - 39.4" |
| X - Axis Travel | 94.4" | 2,397.8 mm |
| Y - Axis Travel | 37.8" | 960.12 mm |
| Z - Axis Travel | 31.5" | 800.1 mm |
| Rapid Traverse Rate - X | 630 in/min. | 16 m/min. |
| Rapid Traverse Rate - Y | 630 in/min. | 16 m/min. |
| Rapid Traverse Rate - Z | 630 in/min. | 16 m/min. |
| Spindle Speed | 8,000 RPM | 8,000 RPM |
| Spindle Taper | #50 | #50 |
| Number of Gear Ranges | 2 | 2 |
| Main Motor | 40 hp | 29.8 kW |
| Automatic Tool Changer | 30 | 30 |
| Tool Diameter | 4.9" / 9.5" | 4.9" / 9.5" |
| Tool Length | 13.8" | 350.52 mm |
| Tool Weight | 33 lb | 15 kg |
| Machine Weight | 57,320 lb | 25,999.9 kg |
| Control | CNC (FANUC 31 IB CNC COLOR CONTROL) | CNC (FANUC 31 IB CNC COLOR CONTROL) |
FANUC 31IB CNC PLUS COLOR CONTROL
RIGID TAPPING
CHIP CONVEYOR
THRU SPINDLE COOLANT
EMBEDDED ETHERNET FUNCTION
DOOSAN TOOL LOAD MONITORING
ALL AVAILABLE MANUALS
FULL ENCLOSURE
HAND HELD REMOTE JOG HANDLE
