Equipment
Lathes CNC, Y-Axis \ Multi-Axis Tasking
Lathes CNC, Y-Axis / Multi Axis
DMG MORI NL 3000Y/3000 CNC MUTLI-TASKING TURNING CENTER

DMG MORI NL 3000Y/3000 CNC MUTLI-TASKING TURNING CENTER

Have one to sell?
(847) 669 9781
mike@usedcncllc.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
Lathes CNC, Y-Axis / Multi Axis
Manufacturer:
DMG MORI
Model:
NL 3000Y/3000
Year:
2007
Stock #:
10066
Status:
For Sale

Description

Explore precision with the used 2007 DMG MORI NL 3000Y/3000 CNC turning center. Features: 16.5" turning diameter, 122.9" turning length, 3,000 RPM spindles, 30 HP, Mori Seiki M720BM CNC control, chip conveyor, and high-pressure coolant.

Turning Diameter16.5"419.1 mm
Turning Length122.9"3,121.7 mm
Distance Between Centers126"3,200.4 mm
Chuck Size 112"304.8 mm
Spindle Nose 1A2-8A2-8
Spindle Bore Diameter 14"101.6 mm
Bar Capacity 14"101.6 mm
Spindle Speeds 13,000 RPM3,000 RPM
Spindle Horsepower 140 hp29.8 kW
X1 - Axis Travel11.8"299.72 mm
Z1 - Axis Travel124.8"3,169.9 mm
Y1 - Axis Travel4.7"119.38 mm
C - Axis Indexing 10.000.00
Rapid Traverse Rate - X11181 ipm
Rapid Traverse Rate - Z11181 ipm
Rapid Traverse Rate - Y1597 ipm
Turret Tool Positions 112 station12 station
Turret Rotary Tool Speeds 16,000 RPM6,000 RPM
Turret Rotary Tool Horse Power 17.5 hp5.6 kW
Tailstock Taper4.04.0
Tailstock Quill Travel3.9"99.06 mm
Tailstock Travel114114
ControlCNC (MORI MSX 805 III CNC COLOR CONTROL)CNC (MORI MSX 805 III CNC COLOR CONTROL)
Weight30800.0030800.00

MORI SEIKI MSX 850 III CNC COLOR CONTROL
CHIP CONVEYOR
TOOL PRESETTER
12" THROUGH HOLE AIR CHUCK
LNS PROGRAMMABLE STEADY REST
(2) ROTARY TOOL HOLDERS
