| Number Of Tables / Pallets | 1 | 1 |
| Table Size - L | 31.5" | 800.1 mm |
| Table Size - W | 25.6" | 650.24 mm |
| Weight On Table | 1,320 lb | 598.7 kg |
| Integrated NC Rotary Table Size | 25.6" | 650.24 mm |
| Main Spindle Horse Power | 47 hp | 35 kW |
| Main Spindle Speeds | 20,000 RPM | 20,000 RPM |
| Max Workpiece Diameter and Height | 33.8" x 19.6" | 33.8" x 19.6" |
| Main Spindle Taper | 63.0 | 63.0 |
| X - Axis Travel | 29.5" | 749.3 mm |
| Y - Axis Travel | 25.6" | 650.24 mm |
| Z - Axis Travel | 22" | 558.8 mm |
| A - Axis Travel | + - 120 Degrees | + - 120 Degrees |
| C - Axis Travel Table Indexing | 360 | 360 |
| Rapid Traverse Rate - X | 1,575 in/min. | 40 m/min. |
| Rapid Traverse Rate - Y | 1,575 in/min. | 40 m/min. |
| Rapid Traverse Rate - Z | 1,575 in/min. | 40 m/min. |
| Cutting Feed Rate | 1,575 in/min. | 40 m/min. |
| Automatic Tool Changer | 60 | 60 |
| Tool Diameter | 6.3", 7.9" | 6.3", 7.9" |
| Tool Length | 15.6" | 396.24 mm |
| Tool Weight | 17.6 lb | 8 kg |
| Machine Weight | 34,092 lb | 15,463.9 kg |
| Control | CNC (CELOS WITH SIEMENS 840D SI OPERATE CNC CONTROL) | CNC (CELOS WITH SIEMENS 840D SI OPERATE CNC CONTROL) |
| Weight | 0.00 | 0.00 |
CELOS WITH SIEMENS 840D sI OPERATE CNC CONTROL
HSK A 63 20,000 RPM Speed Master Spindle
Air Blast Thru Spindle
Chip Conveyor
Economic Production Package
Production Package 40 bar/23 I/min 600 l Tank
Spray Pistol for Chip Rinsing
Oil and Emulsion Mist Separator
Infrared Measuring Probe RENISHAW SK-40
Tool Measuring in Machining area Blum Laser
3D Quickset
VCS Complete
Sensor Package I4.0
Machine Version 60 HZ
Machine Version Inch
MDynamics Package
Electronic Handwheel
Safety Package for Power Failure
DMQP Federal Pacific Transformer 3 Phase
3D Data Model
Chip Blaster Chip Chiller 34,000 btu Standalone
