| Swing Over Bed | 30" | 762 mm |
| Turning Diameter | 30" | 762 mm |
| Turning Length | 60" | 1,524 mm |
| Chuck Size 1 | 10" | 254 mm |
| Spindle Nose 1 | A2 - 8 | A2 - 8 |
| Spindle Bore Diameter 1 | 3.46" | 87.884 mm |
| Bar Capacity 1 | 3" | 76.2 mm |
| Spindle Speeds 1 | 4,000 RPM | 4,000 RPM |
| Spindle Horsepower 1 | 40 hp | 29.8 kW |
| Chuck Size 2 | 10" | 254 mm |
| Spindle Nose 2 | A2 - 8 | A2 - 8 |
| Spindle Bore Diameter 2 | 3" | 76.2 mm |
| Spindle Speeds 2 | 4,000 RPM | 4,000 RPM |
| Spindle Horsepower 2 | 35 hp | 26.1 kW |
| B - Axis Head Indexing | 0 | 0 |
| B - Axis Milling Spindle Taper | KM | KM |
| B - Axis Milling Spindle Speed | 12,000 RPM | 12,000 RPM |
| B - Axis Milling Spindle Horse Power | 25 hp | 18.6 kW |
| ATC For Milling Spindle | 40 | 40 |
| X1 - Axis Travel | 24.8" | 629.92 mm |
| Z1 - Axis Travel | 62.41" | 1,585.2 mm |
| Y1 - Axis Travel | 8.26" | 209.8 mm |
| C - Axis Indexing 1 | 0.001 | 0.001 |
| C - Axis Indexing 2 | 0.001 | 0.001 |
| W - Axis Travel Sub Spindle | 60.24" | 1,530.1 mm |
| Rapid Traverse Rate - X1 | 1496 ipm | |
| Rapid Traverse Rate - Z1 | 1496 ipm | |
| Rapid Traverse Rate - Y1 | 1024 ipm | |
| Control | CNC (MAZAK MAZATROL MATRIX CNC COLOR CONTROL) | CNC (MAZAK MAZATROL MATRIX CNC COLOR CONTROL) |
| Weight | 40000.00 | 40000.00 |
MAZATROL MATRIX CNC COLOR CONVERSATIONAL CONTROL
FULL COLOR GRAPHICS DISPLAY
SYNCH TAPPING ON B AXIS MILLING HEAD
COOLANT THROUGH SPINDLE ON B AXIS MILL HEAD
AUTOMATIC TOOL EYE FOR TOOL LENGTH MEASUREMENT AND TOOL BREAKAGE DETECT
RE THREADING FUNCTION
CHIP CONVEYOR
(1) NEW 12" 3 JAW HYDRAULIC CHUCK INCLUDED
This equipment is currently unavailable. Similar equipment available now is shown below.
