| Number Of Tables / Pallets | 1 | 1 |
| Table-L | 98.4" | 2,499.4 mm |
| Table-W | 37.4" | 949.96 mm |
| Weight on Table | 7,716 lb | 3,499.9 kg |
| X - Axis Travel | 98.4" | 2,499.4 mm |
| Y - Axis Travel | 37.4" | 949.96 mm |
| Z - Axis Travel | 33.5" | 850.9 mm |
| Spindle Speed | 6,000 RPM | 6,000 RPM |
| Spindle Taper | 50 | 50 |
| Number of Gear Ranges | 2 | 2 |
| Main Motor | 40 hp | 29.8 kW |
| Tool Diameter | 4.9", 11.9" | 4.9", 11.9" |
| Tool Length | 13.8" | 350.52 mm |
| Tool Weight | 33 lb | 15 kg |
| Machine Weight | 50,760 lb | 23,024.4 kg |
| Automatic Tool Changer | 40 | 40 |
| Control | CNC (FANUC SERIES I PLUS CNC COLOR CONTROL) | CNC (FANUC SERIES I PLUS CNC COLOR CONTROL) |
| Dimensions | 170" x 255.1" x 141.7" | 170" x 255.1" x 141.7" |
| Weight | 50706 LBS. | 50706 LBS. |
Table Size : 98.4" x 37.4"
Table Load Capacity: 7716 LBS.
X - Axis Travel: 98.4"
Y - Axis Travel: 37.4"
Z - Axis Travel: 33.5"
Spindle Nose : # 50 Big Plus
Spindle Speed: 10,000 RPM
Machining Spindle Horsepower: 40 HP
Rapid Traverse Rate X, Y, Z: 630, 630, 630 IPM
Number Of Tool Change Position: 30 ATC Twin Arm
Max Tool Length: 13.8''
Max Tool Diameter:
Maximum Tool Weight: 33 lbs.
Machine Weight: 50,760 lbs.
DOOSAN FANUC SERIES I CNC CONTROL PLUS
EZ GUIDE CONVERSATIONAL PROGRAMMING
THRU SPINDLE COOLANT 300 PSI
EMBEDDED ETHERNET FUNCTION
DOOSAN TOOL LOAD MONITORING
RIGID TAPPING
CHIP CONVEYOR
This equipment is currently unavailable. Similar equipment available now is shown below.
