| Table Diameter | 39.76" | 1,009.9 mm |
| Table Load Capacity | 2,640 lb | 1,197.5 kg |
| Swing Diameter | 49.2" | 1,249.7 mm |
| Turning Height | 35" | 889 mm |
| Spindle Nose | FLAT 14.96 | FLAT 14.96 |
| Table Speed | 1,250 RPM | 1,250 RPM |
| Main Motor | 60 hp | 44.7 kW |
| Number Of Ranges | 2 | 2 |
| X - Axis Travel | 22.24" | 564.9 mm |
| Z - Axis Travel | 35.04" | 890.02 mm |
| Rapid Traverse Rate - X | 945 ipm | |
| Rapid Traverse Rate - Z | 945 in/min. | 24 m/min. |
| Turret Configuration | 12 station | 12 station |
| Machine Weight | 28,600 lb | 12,972.8 kg |
| Control | CNC (FANUC 31I TB CNC COLOR CONTROL) | CNC (FANUC 31I TB CNC COLOR CONTROL) |
FANUC 31I-TB CNC COLOR CONTROL
HAND HELD MPG
CHIP CONVEYOR & CHIP
39.6 COMBINATION CHUCK SYSTEM
HIGH PRESSURE COOLANT SYSTEM 1000 PSI THROUGH TOOL
TOOL SETTER
MIST COLLECT SYSTEM
