| Swing Over Bed | 22.05" | 560.07 mm |
| Turning Diameter | 13.7" | 347.98 mm |
| Turning Length | 43.31" | 1,100.1 mm |
| Distance Between Spindles | 51.57" | 1,309.9 mm |
| Chuck Size 1 | 12" | 304.8 mm |
| Spindle Nose 1 | A2 -8 | A2 -8 |
| Spindle Bore Diameter 1 | 4.1" | 104.14 mm |
| Bar Capacity 1 | 3.5" | 88.9 mm |
| Spindle Speeds 1 | 3,500 RPM | 3,500 RPM |
| Spindle Horsepower 1 | 30 hp | 22.4 kW |
| Chuck Size 2 | 8" | 203.2 mm |
| Spindle Nose 2 | A2 -5 | A2 -5 |
| Spindle Speeds 2 | 5,000 RPM | 5,000 RPM |
| Spindle Horsepower 2 | 20 hp | 14.9 kW |
| X1 - Axis Travel | 8.76" | 222.5 mm |
| Z1 - Axis Travel | 44.69" | 1,135.1 mm |
| Y1 - Axis Travel | 3.2" | 81.28 mm |
| C - Axis Indexing 1 | 0.001 | 0.001 |
| C - Axis Indexing 2 | 0.002 | 0.002 |
| W - Axis Travel Sub Spindle | 47.75" | 1,212.8 mm |
| Rapid Traverse Rate - X1 | 629 ipm | |
| Rapid Traverse Rate - Z1 | 786 ipm | |
| Rapid Traverse Rate - Y1 | 394 ipm | |
| Turret Tool Positions 1 | 12 station | 12 station |
| Turret Rotary Tool Speeds 1 | 6,000 RPM | 6,000 RPM |
| Turret Rotary Tool Horse Power 1 | 10 hp | 7.5 kW |
| Machine Weight | 25,000 lb | 11,339.8 kg |
| Control | CNC | CNC |
| Weight | 10230.00 | 10230.00 |
FANUC 0I-TF CNC COLOR CONTROL
ALL AVAILABLE MANUALS
CHIP CONVEYOR
12 POSITION TURRET
BAR FEED INTERFACE
AUTO PARTS CATCHER TYPE
HELICAL INTERPOLATION
TOOL SETTER MAIN AND SUB SPINDLE
3 AXIAL AND 4 RADIAL MILLING HOLDERS
4.1" BIG BORE MAIN SPINDLE OPTION
R & D FACILITY 2000 HOURS ONLY
This equipment is currently unavailable. Similar equipment available now is shown below.
