| Number Of Tables / Pallets | 1 | 1 |
| Table-L | 26" | 660.4 mm |
| Table-W | 15" | 381 mm |
| Weight on Table | 250 lb | 113.4 kg |
| Spindle Nose to Table Top | 6" ~ 21.5" | 6" ~ 21.5" |
| X - Axis Travel | 20" | 508 mm |
| Y - Axis Travel | 16" | 406.4 mm |
| Z - Axis Travel | 15.5" | 393.7 mm |
| Rapid Traverse Rate - X | 2,400 in/min. | 61 m/min. |
| Rapid Traverse Rate - Y | 2,400 in/min. | 61 m/min. |
| Rapid Traverse Rate - Z | 2,400 in/min. | 61 m/min. |
| Cutting Feed Rate | 1,200 in/min. | 30.5 m/min. |
| Spindle Speed | 15,000 RPM | 15,000 RPM |
| Spindle Taper | 30 BT | 30 BT |
| Main Motor | 15 hp | 11.2 kW |
| Automatic Tool Changer | 20 | 20 |
| Tool Diameter | 2" | 50.8 mm |
| Tool Length | 7" | 177.8 mm |
| Machine Weight | 5,150 lb | 2,336 kg |
| Control | CNC (HAAS CNC CONTROL) | CNC (HAAS CNC CONTROL) |
HAAS CNC CONTOL
WHIPS PROBING
RENISHAW PART PROBE
TOOL LENGTH MEASUREMENT PROBE
FULL ENCLOSUERS
RIGID TAPPING
PROGRAMMABLE COOLANT NOZZLE
COOLANT THRU SPINDLE
ALL AVAILABLE MANUALS
This equipment is currently unavailable. Similar equipment available now is shown below.
