| Swing Over Bed | 25.6" | 650.24 mm |
| Machining Length | 21.7" | 551.18 mm |
| Turning Diameter, Shaft Diameter | 15.7" | 398.78 mm |
| Chuck Size 1 | 8" | 203.2 mm |
| Spindle Nose 1 | A2 - 6 | A2 - 6 |
| Spindle Bore Diameter 1 | 3.2" | 81.28 mm |
| Spindle Bar Capacity 1 | 2.6" | 66.04 mm |
| Spindle Speeds 1 | 4,500 RPM | 4,500 RPM |
| Spindle Horsepower 1 | 25 hp | 18.6 kW |
| X1 - Axis Travel | 9.05" | 229.87 mm |
| Z1 - Axis Travel | 22.8" | 579.12 mm |
| C1 - Axis Travel | .001 | .001 |
| Rapid Traverse Rate - X1 | 945 in/min. | 400.1 mm/sec. |
| Rapid Traverse Rate - Z1 | 1,181 in/min. | 500 mm/sec. |
| Turret Configuration 1 | 1255 | 1255 |
| Turret Rotary Tool Spindle Speed 1 | 6,000 RPM | 6,000 RPM |
| Turret Rotary Tool Horse Power 1 | 7.5 hp | |
| Tailstock Quill Diameter | 3.1" | 78.74 mm |
| Tailstock Taper | MT 3 | MT 3 |
| Tailstock Quill Travel | 3.9" | 99.06 mm |
| Tailstock Travel | 22.8" | 579.12 mm |
| Tailstock | 'Yes' | 'Yes' |
| Sub Spindle | 'No' | 'No' |
| Control | CNC (FANUC SERIES I PLUS CNC COLOR CONTROL) | CNC (FANUC SERIES I PLUS CNC COLOR CONTROL) |
| Weight | 8200.00 | 8200.00 |
FANUC SERIES I PLUS CNC COLOR CONTROL
CHIP CONVEYOR
TOOL PRESETTER
(2 ) I.D. ROTARY HEADS
(2) O.D. ROTARY HEADS
STANDARD STATIC TOOL PACKAGE
DOOSAN TOOL LOAD MONITORING
EHTERNET
478 CUTTING HOURS
