| Number Of Tables / Pallets | 1 | 1 |
| Table-L | 26" | 660.4 mm |
| Table-W | 15" | 381 mm |
| Weight on Table | 250 lb | 113.4 kg |
| Spindle Nose to Table Top | 6" ~ 21.5" | 6" ~ 21.5" |
| X - Axis Travel | 20" | 508 mm |
| Y - Axis Travel | 16" | 406.4 mm |
| Z - Axis Travel | 15.5" | 393.7 mm |
| Rapid Traverse Rate - X | 2,400 in/min. | 61 m/min. |
| Rapid Traverse Rate - Y | 2,400 in/min. | 61 m/min. |
| Rapid Traverse Rate - Z | 2,400 in/min. | 61 m/min. |
| Cutting Feed Rate | 1,200 in/min. | 30.5 m/min. |
| Spindle Speed | 15,000 RPM | 15,000 RPM |
| Spindle Taper | 30 BT | 30 BT |
| Main Motor | 15 hp | 11.2 kW |
| Automatic Tool Changer | 20 | 20 |
| Tool Diameter | 2" | 50.8 mm |
| Tool Length | 7" | 177.8 mm |
| Machine Weight | 5,150 lb | 2,336 kg |
| Control | CNC | CNC |
Number Of Tables / Pallets: 1
Table Size : 26" X 15"
Weight On Table: 250 LBS.
Integrated NC Rotary Table Size: 0
Spindle Nose To Table: 6" ~ 21.5"
X - Axis Travel: 20"
Y - Axis Travel: 16"
Z - Axis Travel: 15.5"
A - Axis Travel: 0
B - Axis Travel: 0
C - Axis Travel Table Indexing: 0
Rapid Traverse X, Y, Z: 2400 IPM
Cutting Feed Rate: 1200 IPM
Spindle Speed: 10,000 RPM
Spindle Taper: 30
Number Of Gear Ranges: 0
Main Motor: 15 HP
Vertical Turning Table Size, Number Of Tables: 0
Table Spindle Speed Vertical Turning: 0
Table Spindle Horse Power Vertical Turning: 0
Automatic Tool Changer: 20 + 1 ATC
Tool Diameter: 2.0"
Tool Length: 7"
Tool Weight: 0
Machine Weight: 5500 LBS
HAAS CNC CONTOL
WHIPS PROBING
RENISHAW PART PROBE
TOOL LENGTH MEASUREMENT PROBE
FULL ENCLOSUERS
RIGID TAPPING
PROGRAMMABLE COOLANT NOZZLE
COOLANT THRU SPINDLE
ALL AVAILABLE MANUALS
This equipment is currently unavailable. Similar equipment available now is shown below.
